Outdoor Isolated Bibs SR02/O - Bodytone
EN STOCK
€2,699.00
Tax included
289 € par mois
675 € par mois
242 € par mois
15 jours ouvré
289 € par mois
675 € par mois
242 € par mois
Discover the SR02/O Outdoor Isolateral Bib from Bodytone, a professional strength training device from the Solid Rock range. With its innovative design and cutting-edge technology, it guarantees careful aesthetics and exceptional durability. Thanks to its structure and automotive quality paint, this equipment will resist bad weather for more than 10 years. Opt for quality and resistance with Solid Rock devices.
The SR02/O Outdoor Isolated Bib from the Bodytone brand is a professional strength training device from the Solid Rock range. This product stands out for its innovative design and exceptional quality. It is specially designed for outdoor use, providing an ideal solution for outdoor fitness areas.
The structure of this device is robust and solid, thanks to the use of high quality materials. The 110 x 52 mm steel tubes with a thickness of 3 mm are welded in accordance with UNE 10219, quality S-275-J0H. The folding process is enriched and optimized to maintain a constant section, thus avoiding sensitive areas and minimizing the breakage rate. In addition, the cold bending process, using a 4-roller system, avoids any deformation and preserves the physical characteristics of the device.
The paint on this bib is also high quality. It is composed of 5 layers of paint, with a thickness of 200 microns. The steel parts are pickled and stabilized by total immersion in different degreasing solutions, thus ensuring perfect and complete cleaning of the base material. A zinc phosphate rust inhibitor primer is applied to isolate internal oxidation and ensure good paint adhesion. The last 3 layers of paint are epoxy polyester powder, specially designed for outdoor use and dried at 240°C. A surface layer of protective polyester varnish is also applied.
The assembly of this bib is carried out with an 11 mm plate-to-plate system, thus avoiding gaps and twists in the maximum effort zones. An ergonomic and biomechanical study was carried out to optimize each exercise. The assembled dimensions are 148 x 160 x 193 cm, providing an ideal working area for the upper gear.
The non-slip tips on the four bases of the device guarantee optimal stability during use. SKF 6205 2Z stainless steel bearings ensure smooth, consistent movement. The regulation levers are made of AISI 316 stainless steel, specially designed to resist corrosion in a marine environment. They are adjustable with 8 laser-engraved positions, offering great flexibility of use. The anodized aluminum handles are knurled to promote a comfortable grip. The pins are made of AISI 316 stainless steel, providing superior corrosion resistance.
In summary, the Bodytone SR02/O Outdoor Isolated Bib is a high-quality professional strength training device, designed for outdoor use. Its solid structure, durable paint and innovative design make it an ideal choice for outdoor fitness spaces.
Features:
Range: Professional
Training type: Strength
Product Range: Bold
Sport: Bodybuilding
Net Weight: 217 kg
structure: Steel tubes of 110 x 52 mm with a thickness of 3 mm. Welded in accordance with UNE 10219, quality S-275-J0H. Enriched and optimized to maintain a constant section in the folding process, thus avoiding sensitive areas and minimizing the breakage rate. Cold bending process, using a 4-roller system, avoiding any deformation in the process and maintaining the physical characteristics of the entire part. Closed perimeter welding at structural points and connection plates.
units: 1
area of use: Outdoor
Weight: 217 kg
Painting: 5 coats of paint. 200 microns Steel pickled and stabilized by total immersion of the parts in different degreasing solutions to guarantee perfect and complete cleaning of the base material. Zinc phosphate anti-rust primer to ensure good insulation from internal oxidation and good paint adhesion. 3 final coats of epoxy polyester powder paint, special for exteriors, drying at 240°C. Surface layer of protective polyester varnish.
assembly process: 11 mm plate-to-plate system, to avoid gaps and twists in areas of maximum effort. An ergonomic and biomechanical study to optimize each exercise.
assembled dimensions: 148 x 160 x 193 cm
Work Area: upper gear
base bases: 4 non-slip tips.
bearings: SKF 6205 2Z. STAINLESS STEEL. Double tapered roller bearing, housed in a closed, anti-backlash bushing, ensuring a constant direction of movement.
regulation levers: Seat post in AISI 316 stainless steel, special anti-corrosion in marine environments. Adjustable with 8 laser engraved positions. Adjustment system using a single bolt, in techno-polymer with a breaking index of 750 kg.
handles: anodized ALUMINUM, knurled for better grip.
axes: Shaft machined from AISI 316 stainless steel, austenitic steels more resistant to corrosion compared to class A2 thanks to the presence of molybdenum, which allows use in aggressive environments such as boiling sulfuric acid or in environments containing chlorides up to certain levels. Widely used in the pulp, food and marine industries. Its support is made of 10mm thick laser cut plates with another 10mm thick plate to reinforce and achieve smooth movement without gaps or twisting caused by continuous use or loading.
capacity: 4 on each arm, 5 or 10 kg discs (discs not included)
measurements: 148 x 160 x 193 cm
The structure of this device is robust and solid, thanks to the use of high quality materials. The 110 x 52 mm steel tubes with a thickness of 3 mm are welded in accordance with UNE 10219, quality S-275-J0H. The folding process is enriched and optimized to maintain a constant section, thus avoiding sensitive areas and minimizing the breakage rate. In addition, the cold bending process, using a 4-roller system, avoids any deformation and preserves the physical characteristics of the device.
The paint on this bib is also high quality. It is composed of 5 layers of paint, with a thickness of 200 microns. The steel parts are pickled and stabilized by total immersion in different degreasing solutions, thus ensuring perfect and complete cleaning of the base material. A zinc phosphate rust inhibitor primer is applied to isolate internal oxidation and ensure good paint adhesion. The last 3 layers of paint are epoxy polyester powder, specially designed for outdoor use and dried at 240°C. A surface layer of protective polyester varnish is also applied.
The assembly of this bib is carried out with an 11 mm plate-to-plate system, thus avoiding gaps and twists in the maximum effort zones. An ergonomic and biomechanical study was carried out to optimize each exercise. The assembled dimensions are 148 x 160 x 193 cm, providing an ideal working area for the upper gear.
The non-slip tips on the four bases of the device guarantee optimal stability during use. SKF 6205 2Z stainless steel bearings ensure smooth, consistent movement. The regulation levers are made of AISI 316 stainless steel, specially designed to resist corrosion in a marine environment. They are adjustable with 8 laser-engraved positions, offering great flexibility of use. The anodized aluminum handles are knurled to promote a comfortable grip. The pins are made of AISI 316 stainless steel, providing superior corrosion resistance.
In summary, the Bodytone SR02/O Outdoor Isolated Bib is a high-quality professional strength training device, designed for outdoor use. Its solid structure, durable paint and innovative design make it an ideal choice for outdoor fitness spaces.
Features:
Range: Professional
Training type: Strength
Product Range: Bold
Sport: Bodybuilding
Net Weight: 217 kg
structure: Steel tubes of 110 x 52 mm with a thickness of 3 mm. Welded in accordance with UNE 10219, quality S-275-J0H. Enriched and optimized to maintain a constant section in the folding process, thus avoiding sensitive areas and minimizing the breakage rate. Cold bending process, using a 4-roller system, avoiding any deformation in the process and maintaining the physical characteristics of the entire part. Closed perimeter welding at structural points and connection plates.
units: 1
area of use: Outdoor
Weight: 217 kg
Painting: 5 coats of paint. 200 microns Steel pickled and stabilized by total immersion of the parts in different degreasing solutions to guarantee perfect and complete cleaning of the base material. Zinc phosphate anti-rust primer to ensure good insulation from internal oxidation and good paint adhesion. 3 final coats of epoxy polyester powder paint, special for exteriors, drying at 240°C. Surface layer of protective polyester varnish.
assembly process: 11 mm plate-to-plate system, to avoid gaps and twists in areas of maximum effort. An ergonomic and biomechanical study to optimize each exercise.
assembled dimensions: 148 x 160 x 193 cm
Work Area: upper gear
base bases: 4 non-slip tips.
bearings: SKF 6205 2Z. STAINLESS STEEL. Double tapered roller bearing, housed in a closed, anti-backlash bushing, ensuring a constant direction of movement.
regulation levers: Seat post in AISI 316 stainless steel, special anti-corrosion in marine environments. Adjustable with 8 laser engraved positions. Adjustment system using a single bolt, in techno-polymer with a breaking index of 750 kg.
handles: anodized ALUMINUM, knurled for better grip.
axes: Shaft machined from AISI 316 stainless steel, austenitic steels more resistant to corrosion compared to class A2 thanks to the presence of molybdenum, which allows use in aggressive environments such as boiling sulfuric acid or in environments containing chlorides up to certain levels. Widely used in the pulp, food and marine industries. Its support is made of 10mm thick laser cut plates with another 10mm thick plate to reinforce and achieve smooth movement without gaps or twisting caused by continuous use or loading.
capacity: 4 on each arm, 5 or 10 kg discs (discs not included)
measurements: 148 x 160 x 193 cm
BT_SR02/O
